- programmable controls for: frame rate; mirror and flip; cropping; windowing
- supports output formats: 12-bit/10-bit RAW RGB
- supports images sizes: full (2688x1520); 1080p (1920x1080); 720p (1280x720); AO_720p (1280x720); AO_360p (640x360)
- standard serial SCCB interface
- up to 4-lane MIPI serial output interface (supports maximum speed up to 1500 Mbps/lane)
- add staggered HDR RAW data output
- programmable I/O drive capability
