- 5.0 megapixel resolution (2592H x 1944V) with 16 border pixels in 1/4” optical format
- Support up to 15 fps with 5MP (JPEG422), 30 fps with analog binning 2x2, 60 fps with analog binning 4x4
- Integrated Image Processing Pipeline functions：Pixel defect correction; Binning resampling; Luminance and color noise reduction; Lens shade correction; Hue / Saturation adjustment; Brightness / Contrast control; Edge enhancement; Color interpolation and correction; Gamma correction
- Embedded imaging sensor controller for automatic exposure control, automatic white balance control, black level compensation, contrast stretching, 50/60 Hz flicker detection and cancelling, and flash support
- Fully programmable independent H and V scaling with derating (max. 1600x1200 FFOV)
- ITU-R BT.656-4 YUV (YCbCr) 4:2:2, RGB 565, RGB 444, RGB 555, JPEG 422 output formats
- 8-bit parallel video interface, horizontal and vertical syncs, 89 MHz (max) clock
