- Back-illuminated and stacked CMOS image sensor
- Digital Overlap High Dynamic Range (DOL-HDR) mode with raw data output.
- High signal to noise ratio (SNR).
- Full resolution @60 frame/s (Normal), 4K2K @60 frame/s (Normal), 1080p @240 frame/s Full resolution @40 frame/s (12 bit Normal), Full resolution @30 frame/s (DOL-HDR, 2 frame)
- Output video format of RAW12/10/8, COMP8.
- Power Save Mode with MIPI ULPS operation
- Pixel binning readout and V sub-sampling function.
- Independent flipping and mirroring.
- Input clock frequency 6 to 27 MHz
- CSI-2 serial data output (MIPI 2lane/4lane, Max. 2.1 Gbps/lane, D-PHY spec. ver. 1.2 compliant)
